Application FAQ of Automatic paper tube grinding head slotting machine

2023.02.06

With the JYD-MK3080 Automatic paper tube grinding head slotting machine being put into production, more and more companies are now using the fully automatic slotting machine in order to save manpower, the following Zhengzhou JYD Machine Co., Ltd, will introduce to you the operation method of the fully automatic slotting machine and the common problems in application.



Operate methods of Automatic paper tube grinding head slotting machine

1. Types of groove arcs and available spectacle lenses
Before grooving, the type of spectacle lens grooving should be clarified first according to the vertex power, refractive characteristics, and spectacle lens design scheme of the spectacle lens. There are three types of grooves for spectacle lenses: management center groove, front arc groove, and rear arc groove.
JYD-MK3080 Automatic paper tube grinding head slotting machine management center slot: suitable for thin spectacle lenses with the same edge thickness, such as plain lenses, mild to moderate hyperopia lenses, or mild myopia lenses;
Front arc groove: suitable for spectacle lenses with thick edges, such as high aspect ratio myopia lenses, deep myopia combined with high astigmatism spectacle lenses.
Back arc groove: suitable for high aspect ratio hyperopia lenses, and bifocal lenses.

2. Clip-on spectacle lenses
JYD-MK3080 Automatic paper tube grinding head slotting machine turn the right clamping knob clockwise, and the right collet is open, install the spectacle lenses according to the spectacle lens installation diagram reminded on the top of the equipment head, turn the right clamping knob in the opposite direction, turn off the right collet, and fix the spectacle lenses.

3. Set the groove type
(1) Set the management center slot
1) Referring to the adjustment table, insert both sides of the elastic hook into the 2 connecting point holes marked with “C” below;
2) Insert the management center pin into the management center hole in the middle of the two guiding arms;
3) Rotate the slotting locator to the management center.
(2) Set the front arc groove
1) Referring to the adjustment table, insert the yellow hook into the 2 connection point holes marked with an “F” mark and “C” mark;
2) Keep the management center pin suspended in the air, and do not insert it into the management center hole between the two guiding arms;
3) Rotate the slotted locator to the front guide arm.
Note: In order to better ensure the firmness of the installation, it is stipulated that the distance between the front arc groove and the front surface of the spectacle lens is not less than 1.0Mm.
(3) Set the back arc groove
1) Referring to the adjustment table, insert the yellow hook into the 2 connection point holes marked with an “R” mark and “C” mark;
2) Keep the management center pin suspended in the air, and do not insert it into the management center hole between the two guiding arms;
3) Rotate the slotted locator to the rear guide arm.
(4) Set the groove depth
Slotted depth adjustment knob, generally, the slotted depth is generally adjusted to 3 to 4 parts.

Application FAQ of Automatic paper tube grinding head slotting machine

1. The JYD-MK3080 Automatic paper tube grinding head slotting machine must be installed on a firm working table. To maintain leveling and smoothness, do not skew, grease each drive shaft position before application, and always keep it clean.
2. There is a small drainage pipe fixed directly in front of the laser cutting wheel of the JYD-MK3080 Automatic paper tube grinding head slotting machine. In addition, there is a cork for the drainage pipe. It is necessary to frequently pull the cork drainage pipe to avoid the rust of the rolling bearing due to too little water storage.
3. The sponge should be removed frequently to clean it up. Before application, it is necessary to introduce sufficient water to wet the sponge. When the sponge is used, it should be replaced immediately.
4. The slot setting should be set at the ultra-thin edge of the spectacle lenses to be processed. The distance between the groove of the spectacle lens and the front edge of the spectacle lens shall not be less than millimeters.
5. The depth of the groove is generally half of the total width, the total width of the groove is 0.5-0.6 mm, and the depth of the groove is generally 0.3 mm. If the depth of the groove is too shallow, the nylon thread is easy to fall off, and if it is too deep, the edge of the spectacle lens is easy to crack.
6. When replacing the laser cutting wheel again, first disconnect the power cord plug, then insert a thin rod into the small round hole of the shaft, and then unscrew the small cross-recessed head screw of the turntable.
